Description Specifications and Drawings


Leine & Linde: Encoders (Industrial 600 Series)

Absolute position encoders that can position single or multi-turn movements.


The inductive 600 series is based on special technology developed to increase the encoder’s durability in demanding environments. Thanks to our inductive scanning method and that robust ball bearings have been used in the series, the product is one of the most robust ø58 mm encoder on the market. The construction provides increased resistance to vibrations and consequently even extends service life.


The 600 series features absolute encoders that can position single or multi-turn movements. The encoders communicate via the serial interfaces SSI and
EnDat, or with advanced fieldbus interfaces such as PROFIBUS, PROFINET, EtherNet/IP or CAN.


Technical Data:

  • Diameter: 58 mm

  • Vibration: 300 m/s2

  • Shock: 2000 m/s2

  • Shaft load radial: 125 N

  • Shaft load axial: 100 N

  • Encapsulation level: IP67

  • Temperature: Variants up to -40 .. +100 ºC
