Crouzet: Miniature Microswitches (831607/832607 Series)
Crouzet: Miniature Microswitches (831607/832607 Series)



Alternate View
Call for Pricing

Price Quote Form


Order #: 83X607


Model Number/Code*:

.
Description Specifications and Drawings


Crouzet: Miniature Microswitches (831607/832607 Series)

With over 60 years’ experience in snap-action technology, Crouzet Switches offers a complete range of Microswitches for the highly demanding markets. The extensive choice consists of standard or customized Sub-subminiature, Subminiature, Miniature and Special microswitches, all conform to the most rigorous quality standards.

Our microswitches are characterized by a large range of switching ratings from 1 mA to 25 A, magnetic blowout versions for High DC ratings, sealed models, positive break versions, a wide range of operating temperatures, models for explosive atmospheres, long service life and wide variety of actuators, contact materials and fixing means.

Miniature Microswitches – Positive Break

(831607 Series)

  • Coil spring snap-action mechanism with wiping contacts

  • Positive opening action according to IEC 60947-5-1 Annex K

  • Very long life

  • Extended range of terminals

  • cURus approved

  • Choice of actuators: stainless steel or plastic

  • Case, Button: PBT GF (UL 94-V0 / GWFI 960 °C)

  • Cover: PC (UL 94-V0 / GWFI 850 °C), transparent

  • Contacts: silver alloy, gold-plated silver alloy (dual-current)

  • Terminals: brass (except W2/X: copper nickel), silver plated common

  • Levers: stainless steel or polyamide, polyamide roller

  • Recommended actuating speed: 0.1 mm/s to 0.5 m/s

  • Rated insulation voltage Ui: 250 V

  • Impulse withstand voltage Uimp: 4 kV

  • Special levers: special shapes and lengths Special connections: angled, screw with clamp (W5), full wiring with custom connector

  • Adjustable fixing by metal threaded barrel (SP9627)

  • Variant for irradiated environment

(832607 Series)

  • Coil spring snap-action mechanism with wiping contacts

  • Positive opening action according to IEC 60947-5-1 Annex K

  • Very long life

  • Extended range of terminals - Stainless steel actuators

  • cURus and CCC approved

  • Case: PET GF (UL 94-V0 / GWFI 960 °C / GWIT 775 °C)

  • Button: PA66 GF (UL 94-V0 / GWFI 960 °C)

  • Contacts: silver alloy

  • Terminals: brass (except W2/X: copper nickel), silver plated common

  • Levers: stainless steel, polyamide roller

  • Recommended actuating speed: 0.25 mm/s to 0.5 m/s

  • Rated insulation voltage Ui: 250 V

  • Impulse withstand voltage Uimp: 4 kV

  • Special levers: special shapes and lengths

  • Lever mounted on position A for higher ratio

  • Special connections: angled, full wiring with custom connector

Specifications

  • Approx body size (mm): 28x16x10

  • Rating (max): 6A / 250Vac

  • Degree of protection: IP40

  • Operating temperature: -40°C/+125°C

  • Operating force (max): 4 N

  • Differential travel (max): 0.3 mm

  • Overtravel (min): 1.3 mm

  • Mechanical life (cycles): 10 M
