Leine & Linde: Ruggedized Incremental Shaft encoder RSI 503 (ID: 517706-07)
Leine & Linde: Ruggedized Incremental Shaft encoder RSI 503 (ID: 517706-07)



Price : $498.00


Availability: 4-5 weeks lead time
Order #: 517706-07
Qty:

Description Specifications and Drawings


Leine & Linde: Ruggedized Incremental Shaft encoder RSI 503 (ID: 517706-07)


RSI 503

Ruggedized Shaft encoder, Incremental

  • Robust encoder with solid shaft
  • Short-circuited protected outputs
  • IP67 at housing, IP66 at shaft inlet


Product data

TypeRSI
Model503 Standard
Shaft typeØ10 mm with partial flat
Flange typeSynchro flange (63-type)
Resolution500 ppr
Power supply9-30 Vdc
Output signalHTL
Connection typePT connector 8-pin
Connecting directionRadial
