Delta: Advanced Multifunction Meter DPM-C530 Delta’s Advanced Multifunction Meter DPM-C530 series offers precise measurement of various electrical energy values and power quality parameters, including power factor, harmonics, and current / voltage unbalance, and it also provides off-limit alarms and history log functions. - Complies with IEC62053-22 Class 0.5S in active energy accuracy
- Supports Modbus communication and is easy to apply with SCADA and EMS
- Capable of measuring total harmonic distortion (THD) and individual harmonics up to the 31st order
- Multi-tariff and demand calculation
- Digital input / output for peripheral integration
- MID ready compliance for billing application in Europe
FeaturesHigh-precision Power Quality and Electricity Parameter Measurement - High-precision Class 0.5S bidirectional energy and electricity parameter measurement, complies with IEC 62053 criteria
- Supports power quality measurement of total / individual harmonic distortion and current / voltage unbalance
Large LCD Screen - Dot matrix LCD display with 198 x 160 dots, supports clear reading and display of English (capital and lowercase letters), Traditional Chinese, Simplified Chinese, Japanese, and other languages
Parameter Grouping Function - The parameter group contains all needed energy data for master controllers (including PLCs, SCADA and EMS) to acquire and reduce reading time, enhancing real-time data accessibility
- Combines several discontinuous register addresses to one continuous address, reducing commands to achieve high-efficiency data acquisition of the master controllers (SCADA and PLC)
Energy Measurement and Alarm History - The management software DPMSoft monitors real-time electricity data, and can easily export all history logs
- Offers energy history logs that can be saved for up to 2 months, and with up to 17 electricity parameters based on various time intervals (example: 17 electricity parameters, 5 minute time intervals for 2 months). 29 built-in alarm events with up to 500 alert history logs
Auto Meter Function - Automatically settles monthly energy consumption (with built-in real-time calendar)
- Adopts a built-in date selected register that records active / reactive energy within a given month interval. Matched with remote communication control or energy management systems, the DPM-C530A can analyze monthly active / reactive energy, multi-rate meter calculation, and conditions of energy usage
Multi-Tariff - Automatic measurement & calculation of power consumption during a specific time period
- Multiple interval groups setting to measure power consumption at different periods of time
Ethernet Communication - Dual Ethernet protocols support Modbus TCP
- Easy serial connection without gateway, no need to occupy communication ports
- Basic settings and data viewing on web page

|
|
|
