Panasonic: AC Motor Standard 1675 RPM 90W 230VAC (M9MZ90G4YGA)
Panasonic: AC Motor Standard 1675 RPM 90W 230VAC (M9MZ90G4YGA)




Panasonic 90 Watt- 4Pole- 90Sq.mm- Three phase- 230 V Ac- 1675Rpm- 1.6N.M- 0.58A- Pinion shaft- Leadwire- 3 phase induction motor

Price : $201.72

Quantity in Stock:18

Availability: Usually Ships in 3 to 5 Business Days
Order #: M9MZ90G4YGA
Qty:

Description Ordering Information Specifications and Drawings


AC Motor Standard 1675 RPM 90W 230VAC (M9MZ90G4YGA)

Panasonic, one of the largest motor manufacturers in the world, have designed and developed a new range of globally approved geared motors. Covering powers from 6 to 90W these units replace the established G-Series range with improved efficiency and longer life, continuing the reputation for quality, value and reliability

Features:

• All ball bearing gearboxes as standard, rated to 10,000 hrs lifetime

• Globally approved CE/ UL/ cUL/ CCC

• Speed range from 1375r/min down to 0.7r/min

• Fixed speed and variable speed models available

• IP 65 available on request

• RoHS compliant

• Proven quality and reliability


Descriptions:

Manufacturer

Panasonic

Product No

M9MZ90G4YGA

Product Type

3-Phase Motor

Size

90 mm sq

Number of pole

4

Output

90W

Number of teeth

9

Weight

3.2 Kg

Shipping weight

4 Kg
