Beckhoff: Industrial PC (CP65xx Series)

The universal built-in Industrial PC with ATX motherboard

The Panel PC series CP65xx is designed for installation in the front of a control cabinet. A built-in Control Panel with DVI and USB interface is the front of the Panel PC. The correct display size and keyboard are thus available for every application. The CP65xx built-in Industrial PCs represent a powerful platform for machine construction and plant engineering applications, for example with the TwinCAT automation software under Windows 7 Professional, Windows 7 Ultimate or Windows Embedded Standard 7.

The 7-slot ATX Panel PCs CP65xx can be equipped with 12-, 15- or 19-inch TFT display, as a monitor without keys or with different types of keyboards. A touch screen or touch pad is optionally available. A large number of push-button extensions are also available.

The CP65xx are equipped with Intel® Celeron® or Core™ i3/i5/i7 processors on an ATX motherboard and have three PCI and four PCI Express slots. A CD/DVD-ROM or multi DVD drive can be installed. A 100 to 240 AC full range power supply or a 24 V DC power supply is used in the PC. The Control Panel is connected to the PC via DVI and USB. The PC deals with the power supply for the Control Panel. The cables are installed in the PC housing.

Model No.: CP6501-0000-0070, CP6501-0000-0080, CP6501-0000-0090, CP6501-0001-0070, CP6501-0001-0080, CP6501-0001-0090, CP6501-0020-0070, CP6501-0020-0080, CP6501-0020-0090, CP6501-0021-0070, CP6501-0021-0080, CP6501-0021-0090, CP6502-0000-0070, CP6502-0000-0080, CP6502-0000-0090, CP6502-0001-0070, CP6502-0001-0080, CP6502-0001-0090, CP6502-0020-0070, CP6502-0020-0080, CP6502-0020-0090, CP6502-0021-0070, CP6502-0021-0080, CP6502-0021-0090, CP6503-0000-0070, CP6503-0000-0080, CP6503-0000-0090, CP6503-0001-0070, CP6503-0001-0080, CP6503-0001-0090, CP6503-0020-0070, CP6503-0020-0080, CP6503-0020-0090, CP6503-0021-0070, CP6503-0021-0080, CP6503-0021-0090, CP6511-0000-0070, CP6511-0000-0080, CP6511-0000-0090, CP6511-0001-0070, CP6511-0001-0080, CP6511-0001-0090, CP6512-0000-0070, CP6512-0000-0080, CP6512-0000-0090, CP6512-0001-0070, CP6512-0001-0080, CP6512-0001-0090, CP6513-0000-0070, CP6513-0000-0080, CP6513-0000-0090, CP6513-0001-0070, CP6513-0001-0080, CP6513-0001-0090, CP6521-0000-0070, CP6521-0000-0080, CP6521-0000-0090, CP6521-0001-0070, CP6521-0001-0080, CP6521-0001-0090, CP6521-0002-0070, CP6521-0002-0080, CP6521-0002-0090, CP6522-0000-0070, CP6522-0000-0080, CP6522-0000-0090, CP6522-0001-0070, CP6522-0001-0080, CP6522-0001-0090, CP6522-0002-0070, CP6522-0002-0080, CP6522-0002-0090, CP6523-0000-0070, CP6523-0000-0080, CP6523-0000-0090, CP6523-0001-0070, CP6523-0001-0080, CP6523-0001-0090, CP6523-0002-0070, CP6523-0002-0080, CP6523-0002-0090, CP6531-0000-0070, CP6531-0000-0080, CP6531-0000-0090, CP6531-0001-0070, CP6531-0001-0080, CP6531-0001-0090, CP6531-0002-0070, CP6531-0002-0080, CP6531-0002-0090, CP6532-0000-0070, CP6532-0000-0080, CP6532-0000-0090, CP6532-0001-0070, CP6532-0001-0080, CP6532-0001-0090, CP6532-0002-0070, CP6532-0002-0080, CP6532-0002-0090, CP6533-0000-0070, CP6533-0000-0080, CP6533-0000-0090, CP6533-0001-0070, CP6533-0001-0080, CP6533-0001-0090, CP6533-0002-0070, CP6533-0002-0080, CP6533-0002-0090, CP6542-0000-0070, CP6542-0000-0080, CP6542-0000-0090, CP6542-0001-0070, CP6542-0001-0080, CP6542-0001-0090
