FANUC: 16-iA BASIC UNIT -A02B-0236-C612

Home > 3R Service Store > Light Used(Works) > Fanuc >

FANUC: 16-iA BASIC UNIT

Call for Pricing
Price Quote Form.

Refurbished
Core Exchange: Option

Repair: Not offering at this time
All our refurbished and repaired FANUC CNC products are thoroughly inspected and tested by certified repair technicians
Validity: 1 Year (Service Warranty).

Availability: Usually Ships in 2 to 3 Weeks
Order #: A02B-0236-C612

Description

Specifications and Drawings

FANUC:16 i-A BASIC UNIT

Part Number: A02B-0236-C612
Product Series: A02B-0236

FEATURES:

The FANUC Series 16i/18i/21i-MODEL-A CNC has two FANUC I/O Link interface channels. These channels make it possible to increase the number of I/O points from 1024/1024 to 2048/2048. This chapter explains how to connect a 2-channel I/O Link connector adapter required in using the I/O Link 2-channel function. Using this function on the 16i/18i/21i-MODEL B mentioned above requires specifying the PMC-SB6/-SB7. This function cannot be used with the PMC on the loader control board.

Two channels' worth of I/O Link signals are allocated to the I/O Link connector (JD44A) of the Series 16i/18i/21i-MODEL B CNC.
