AllMotion: Stepper/Servo Accessories (USB485 Series)

Serial Data Converters - RS485 to USB Converter

The RS-485 bus protocol allows for multiple devices to communicate on a Bidirectional Bus with a master USB Controller such as a PC COM port.

While it is possible to use any commercially available USB to RS485 converter with the EZStepper / EZServo products, this converter has been customized to combine the power wires with the serial data from a standard USB connector and send it to a 4 pin connector that has the same pinout as the EZStepper / EZServo 4 wire bus.

This converter operates from 12V to 40V. Please consult the factory if you need to run at a lower voltage.

Model #: USB485 (with enclosure), USB485 NE (no enclosure)
