ATI: F/T Sensor (Axia130-M125) 9105-NET-AXIA130-M125

Product Advantages

• A high-performance, easy-to-use sensor that offers the highest resolution, accuracy, and stiffness available to provide a sense of touch to your application.
• All of the electronics are built into the transducer body, which keeps the cost down and the footprint smaller. Like all of ATI's F/T products, the Axia130 features superior quality and robustness.
• Available with Ethernet, EtherCAT, and Serial (RS422 and RS485) communication.
• Large thru-hole allows routing cables through center of sensor.
• Extremely High-Strength: Precision-machined from high-strength stainless steel. Maximum allowable single-axis overload values of 5.0 to 10.5 times the maximum measurable loads.
• High Signal-to-Noise Ratio: Strain gages provide exceptional resolution and accuracies better than 2% full scale across all axes and calibrations.
• IP67 Protection from dust, high pressure water spray, and submersion up to 1m for 30 minutes

Typical Applications

• Rehabilitation research
• Product testing
• Robotic assembly
• Telerobotics
• Orthopedic research
• Part placement and removal in precision fixtures
