Description Specifications and Drawings


Galil: Multi-Axis Motion Controller (DMC-18x6 Series)

Galil's multi-axis motion controllers are designed to provide the ultimate performance and flexibility for your application. The DMC-40x0 Series is Galil’s most advanced multi-axis motion control solution, while the DMC-41x3 Series is designed to provide the best value and performance that meets the needs of most applications. Each model operates stand-alone or is networked to a PC via Ethernet 100Base-T, RS232, or USB. Integrated drives for steppers and servos minimize space, cost, and wiring. Plenty of uncommitted I/O for synchronizing motion with external events.

PCI Multi-Axis Controllers, 1-8 axes

The DMC-18x6 motion controller is part of the family, Galil's highest performance PCI bus motion controller. It belongs to Galil's latest generation motion controller family: the DMC-40x0 Series, which accepts encoder inputs up to 22 MHz, provides servo update rates as high as 32 kHz, and processes commands as fast as 40 microseconds-10 times the speed of prior generation controllers.

The DMC-18x6 is a full-featured, PCI motion controller card. The DMC-18x6 is available in one through eight-axis formats, and each axis is user-configurable for stepper or servo motor operation. With a powerful RISC processor, the DMC-18x6 controllers provide such advanced features as PID compensation with velocity and acceleration feedforward, program memory with multitasking for simultaneously running eight applications programs, optically isolated digital I/O, and uncommitted analog inputs. Modes of motion include point-to-point positioning, position tracking, jogging, linear and circular interpolation, contouring, electronic gearing and ecam.

Like all Galil controllers, programming the DMC-18x6 is simplified with two-letter, intuitive commands and a full set of software tools such as GalilSuite for servo tuning and analysis.


Features

  • PCI card in 1 through 8 axis versions: DMC-18x6 where x=1,2,3,4,5,6,7,8 axes

  • User-configurable for stepper or servo motors on any combination of axes

  • Accepts up to 22 MHz encoder frequencies for servos and outputs up to 6MHz for steppers

  • Sample times as low as 31 microseconds per axis; Ultra-fast command processing.

  • Advanced PID compensation with velocity and acceleration feedforward, integration limits, notch filter and low-pass filter

  • Modes of motion include jogging, point-to-point positioning, position tracking, contouring, linear and circular interpolation, electronic gearing and ECAM. Ellipse scaling, slow-down around corners, infinite segment feed and feed rate override

  • Multitasking for concurrent execution of up to eight application programs.

  • Expanded, non-volatile memory for application programs, variables and arrays

  • Dual encoders for every servo axis

  • Optically isolated home input and forward and reverse limits accepted for every axis

  • 8 isolated, uncommitted inputs and 8 outputs for 1- through 4-axes models, 24 inputs and 16 outputs for 5- through 8-axis models

  • Expansion for 64 I/O with optional DB-14064

  • 8 uncommitted analog inputs

  • High speed position latch and output compare

  • 2nd FIFO for instant access to status and parameters

  • High-density shielded cables and optical isolation for noise immunity.

  • Connects directly to AMP-19540 4-axis drive for cost-effective, multi-axis controller/drive solution. Drives brush or brushless servos up to 500 Watts each. Or, connect to external drives of any power range using ICM-2900 interconnect module

  • Communication drivers for Windows, QNX, and Linux

  • Custom hardware and firmware options available


Model No.:
DMC-1816, DMC-1826, DMC-1836, DMC-1846, DMC-1856, DMC-1866, DMC-1876, DMC-1886
