Description Specifications and Drawings


Crouzet: Subminiature Microswitches (83151 Series)

With over 60 years’ experience in snap-action technology, Crouzet Switches offers a complete range of Microswitches for the highly demanding markets. The extensive choice consists of standard or customized Sub-subminiature, Subminiature, Miniature and Special microswitches, all conform to the most rigorous quality standards.

Our microswitches are characterized by a large range of switching ratings from 1 mA to 25 A, magnetic blowout versions for High DC ratings, sealed models, positive break versions, a wide range of operating temperatures, models for explosive atmospheres, long service life and wide variety of actuators, contact materials and fixing means.

Subminiature Microswitches – Hermetic Inox Housing

  • Switching power from 1 mA to 7 A

  • Vibration resistant up to 80 G

  • Shock resistant up to 200 G

  • High level of hermetic sealing

  • Long life: 200 000 cycles

  • Numerous single pole and multipoles operating and fixing option

Specifications

  • Approx body size (mm): Ø11×15

  • Rating (max): 5A/250Vac

  • Degree of protection: Hermetic 10-3Pa.cm3/s

  • Operating temperature: -55°C/+250°C

  • Operating force (max): 5 –> 47N

  • Differential travel (max): 0.05 mm

  • Overtravel (min): 0.08 mm

  • Mechanical life (cycles): 0.2 M
